W 2 5 C G D B

_ _ _ _ - _ _ - _ - _ - _ - _ - _ - _ _ _ - _ _ - _

PROD. ID

VOLTAGE COLOR

OPTIONS

FUNCTION

LENS

TYPE

LAMP BASE

WATTAGE

LIGHT

SOURCE

Ordering Number Logic

Wallighter

250 Cutoff (W25C)

BALLAST

TYPE

SELECTION

1 = None

3 = Internal

*PE control

For PE Kit, see

Accessories

* Not available

with multivolt

or 480V

W25C =

Wallighter 250

(250 watt max.)

luminaire with

cutoff optics

See Ballast and

Photometric

Selection Table

05 = 50

07 = 70

10 = 100

15 = 150 (55V)

17 = 175

20 = 200

25 = 250

77 = 70/75

See Ballast and

Photometric

Selection Table

E = Energy Act

Compliant Pulse

MH (EPMH)

S = HPS

M = MH

P = PMH

See Ballast and

Photometric

Selection Table

60Hz

0 = 120/208/

240/277

Multivolt

1 = 120

2 = 208

3 = 240

4 = 277

5 = 480

C = 120x240x

277V

D = 347

F = 120X347

G = Glass

For IES Optical

Conﬁguration

See Ballast and

Photometric

Selection Table

MGL = Mogul base

E39 (Standard

without lamp)

MED = Medium base

E26 (Standard with

lamp)

See Ballast

and Photometric

Selection Table

A = Autoreg

G = Mag-Reg

with

Grounded

Socket Shell

H = HPF

Reactor or

Lag

K = Hot Restart

M = Mag-Reg

N = NPF

Reactor or

Lag

P = CWI with

Grounded

Socket Shell

B = Time Delay

Automatically

Switched Quartz

F = Fusing (Not available

with multivolt)

DB = Dark Bronze

All light sources are clear unless otherwise indicated.

IES Photometric

Light Distribution Curve Number

Wattage Source Multivolt 120 208 240 277 480 347, 120X347 Type 35-

MOGUL BASE LAMP (NOT INCLUDED)

50 HPS H H, K, N H H H N/A H SC3 178825

70, 100, 150(55V) HPS H G, H, K, M G, H, M G, H, M G, H, M G, H, M G**, M SC3 178825

200* HPS A A A A A C/F A SC3 178830

250* HPS A A A A A A A SC3 178830

175 EPMH N/A N/A N/A N/A N/A N/A N/A SC3 178828

250* EPMH A A A A A A A SC3 178831

CANADA ONLY

175 MH N/A A A A A N/A A SC3 178828

250* MH N/A A, P A, P A, P A, P P A, P SC3 178831

MEDIUM BASE LAMP (INCLUDED)

50, 70, 100, 150(55V) HPS N N N/A N/A N/A N/A N/A SC3 178833

70, 100, 150**** MH H*** N/A N/A N/A N/A N/A N/A SC3 178835

NOTE: *Horizontal lamp operation. C/F = Contact Manufacturer N/A = Not Available

**347 Volt Only ***150W PMH Available in Tri-Volt Multivolt: 120X208X277V or 120X240X277V

****150W PMH Only available in HPF-LAG (H) Ballast Type for 120 or 208 or 240 or 277V and Auto-Reg (A) in 120 or 277V

Ballast and Photometric Selection Table

Ballast Type/Voltage

60Hz

1 2 3 4
